Circuit Diagrams of Electrical Appliances
21-49
IC02F: instrument panel harness--front harness (26P White) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 2606 Green D020A ALL 14 5111 Red D500 ALL
2 012C Brown SP08 ALL 15 6739 Brown S002B B /C
3 8200 Red D820 ALL 15 6739E Brown D004A E/F
3 8200A Green D820 ALL 15 6739G Brown D721 E/F
4 7002 Grey D003 ALL 16
5 8269 Blue D820 ALL 17
6 602B Brown D001C ALL 18
7 1012 Brown D004B ALL 19 1599B Green D003 ALL
8 2500 Red D020B ALL 20 602 Red IC05F ALL
9 9006B Yellow D003 ALL 21
10 601 Pink IC04F ALL 22 5112 Brown D500 ALL
11 7003 Red D004B ALL 23 7020 White IC04F ALL
12 5016 Yellow D500 ALL 24 7021 Red IC04F ALL
13 2100A Green S001 ALL 25 7025 Green IC04F ALL
26 7026 Brown IC04F ALL
IC03F: instrument panel harness--front harness (2P Brown) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 260 White SP05 ALL 2 803 Red IC12F E/F
2 803A Red IC13F B/C
IC04F: instrument panel harness--cockpit harness (22P Black) (S30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 7020 White IC02F ALL 12 6017 Brown IC05F ALL
2 7021 Red IC02F ALL 13 2325 Yellow SP15 ALL
3 2320 Red SP14 ALL 14 601 Pink IC02F ALL
4 2330 Brown SP14 ALL 15 6411 Blue IC05F ALL
5 8425 Green D840B ALL 16 8426 Yellow D840B ALL
6 6412 Red IC05F ALL 17 6401 Blue IC05F ALL
7 8420 Yellow D840B ALL 18 8421 Green D840B ALL
8 1202 Grey D004A ALL 19 7026 Brown IC02F ALL
9 7025 Green IC02F ALL 20 8411 Red D840B ALL
10 8410 Green D840B ALL 21 2100B Green S001 ALL
11 2201 Brown IC01F ALL 22 6019 Yellow IC05F ALL
