Circuit Diagrams of Electrical Appliances
21-63
IC13F: instrument panel harness--automatic air conditioning harness (16P Grey) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 2600H Red SP07 B/C 9 MC52A
Yellow
green
G52 B/C
2 8100A Red D001H B/C 10 MC53A
Green
yellow
G53 B
3 MC803
Yellow
green
D8013 B/C 11 MC804
Green
yellow
IC05F B/C
4 6739B Green S002B B/C 12 8081A Yellow IC01F B/C
5 8013 Red D8013 B/C 13 8080A Grey IC01F B/C
6 8011 Yellow IC05F B/C 14
6 8011A Yellow D721 B/C 15 8077A Brown IC01F B/C
7 8001A Brown IC01F B/C 16 803A Red IC03F B/C
8 003D Green SP21 B/C
IC14M: instrument panel harness--SRS harness (10P Green) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 652 Brown D001B ALL 6
2 6501 Green D004B ALL 7
3 8 6502 Brown D001H ALL
4 9006A Brown D003 ALL 9
5 6503 Green D004A ALL 10
IC15AF: instrument panel harness--driver airbag (2P Yellow) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6510 Orange IC15M ALL 2 6511 Yellow IC15M ALL
IC15M: instrument panel harness--SRS harness (2PBrown) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6510 Orange IC15AF ALL 2 6511 Yellow IC15AF ALL
IC16M: instrument panel harness--SRS harness (2P Green) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6515 Orange ICI6AF ALL 2 6516 Yellow ICI6AF ALL
IC16AF: instrument panel harness--passenger airbag (2P Green) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 6515 Orange IC16M ALL 2 6516 Yellow IC16M ALL
