Circuit Diagrams of Electrical Appliances
21-64
IC22F: instrument panel harness--front harness (20P White) (H30)
Pin
Conductor
No.
Colour Connection Model Pin
Conductor
No.
Colour Connection Model
1 010E Yellow SP10 C/F 11 1623 Red D1603 C/F
2 1622 Blue D1603 C/F 12 1620 Brown D1603 C/F
3 13
4 1621 Grey D1603 C/F 14
5 1631 Green D1604 C/F 15
6 1632 Grey D1604 C/F 16
7 7309 Red D210A C/F 17
8 18
9 1625 Yellow D1603 C/F 19 9000 Green D004A C/F
10 1624 Green D1603 C/F 19 9000B Green D003 C/F
20 9001 Brown D004A C/F
20 9001B Brown D003 C/F
