Circuit Diagrams of Electrical Appliances
21-10
Electrical appliance components Pin (P) Colour of connector
D840(rearview mirror fuse) 2
D840A(radio cassette player A) 8 Black
D840B(radio cassette player B) 8 White
D8410A(bass horn) 2 Black
D8410B(high-pitched horn) 3 Black
D8415A(woofer) 2 Black
D8415B(tweeter) 3 Black
D8420(woofer) 2 Black
