Doogee S88 - G.5 Wound Components

- Page 25 of 60 -
Report No. STS200421001001E
IEC/EN 62368-1
Clause Requirement + Test Result - Remark Verdict
Shenzhen NTEK Testing Technology Co., Ltd
Test Voltage (V) and Insulation Resistance () . :

G.3.3 PTC Thermistors N/A
G.3.4 Overcurrent protection devices N/A
G.3.5 Safeguards components not mentioned in G.3.1 to G.3.5 N/A
G.3.5.1 Non-resettable devices suitably rated and
marking provided
N/A
G.3.5.2 Single faults conditions ........................................ : N/A
G.4 Connectors
N/A
G.4.1 Spacings Not directly connected to mains N/A
G.4.2 Mains connector configuration ........................... : N/A
G.4.3 Plug is shaped that insertion into mains socket-
outlets or appliance coupler is unlikely
N/A
G.5 Wound Components
N/A
G.5.1 Wire insulation in wound components ................ : N/A
G.5.1.2 a) Two wires in contact inside wound component,
angle between 45° and 90°
N/A
G.5.1.2 b) Construction subject to routine testing N/A
G.5.2 Endurance test on wound components N/A
G.5.2.1 General test requirements N/A
G.5.2.2 Heat run test N/A
Time (s) ............................................................... :

Temperature (C) ................................................ :

G.5.2.3 Wound Components supplied by mains N/A
G.5.3 Transformers
N/A
G.5.3.1 Requirements applied (IEC61204-7, IEC61558-
1/-2, and/or IEC62368-1) .................................... :
N/A
Position ................................................................ :

Method of protection ........................................... :

G.5.3.2 Insulation N/A
Protection from displacement of windings ........... :

G.5.3.3 Overload test ...................................................... :
N/A
G.5.3.3.1 Test conditions
N/A
G.5.3.3.2 Winding Temperatures testing in the unit
N/A
G.5.3.3.3 Winding Temperatures - Alternative test method N/A
G.5.4 Motors
P
