Doohan DH01 - Main Technical Specifications; Vehicle Dimensions and Performance Data

IX、Main technical data
Main dimensions
vehicle length
1780mm
vehicle width
730mm
vehicle height
1030mm
Wheelbase
1250mm
Track front
460mm
Main performance
Curb weight
99kg
Designed maximum
speed
First gear 25km/h
Second gear 45km/h
Rated voltage
60V
Maximum Payload
160kg
Braking distance（dry
land）
≤2m(20km/h)
≤3.5m(30km/h)
Personnel quota
1 person
Climbing ability
≤25%（Load 80KG）
Braking distance（wet
land）
≤3m(20km/h)
≤4m(30km/h)
The standard
power
consumption
2KWh/100km(20km/h)
Frame
front shock absorber
Sleeve、Oil Damping Type
rear shock absorber
Sleeve、Oil Damping Type
Front tire Type
80/100-12×2
Rear tire Type
120/70-12
Front Brake Mode
160mm Rotor Double-piston Hydraulic Disc
Rear Brake Mode
190mm Rotor Double-piston Hydraulic Disc
Minimum Ground Clearance
130mm
