Ass,Pull rod of ball head, Steering knuckle axletree assy
Sequence
of
Operation
Spare parts name
Quantities
Remarks
1
2
3
4
5
Disassemble the ball head rod assy
M10,Hexagonal flange iron self-locking
nut
Pull rod of ball head, assy
M10×60,Hexagonal flange bolt
Steering knuckle axle assy
Spacer assy,bracket plate of steering
knuckle.
2
1
2
1
1
Disassemble parts in order
Attention
Both sides is symmetrical, Don’t
need to remove both sides when one
side need to service.
Parts assembling with the reverse order
of disassembling.
