Door Controls PS17-TD2 - Page 7

PS17-TD2 - 7 -
Fig. 7 - Latching fire alarm tie-in with manual reset:
Fig. 5 - Typical dual mag lock installation with fire alarm tie-in
using trigger controlled outputs:
Fig. 8 - Multiple PS17-TD2 power supply connections:
Fig. 4 - Typical single mag lock or door strike installation with
fire alarm tie-in using trigger controlled output:
Fig. 6 - Typical mag lock with fire alarm tie-in using aux.
output installation:
PS17-TD2 #1 PS17-TD2 #2
Application Diagrams when used as a typical power supply not using delay features:
FACP
MAG LOCK
DOOR
STRIKE
PROX/CARD
READER
ACCESS
CONTROL
DEVICE
LOCK +
STRIKE +
TRG2
TRG1
AUX +
AUX --
COM --
FACP
MAG LOCK
ACCESS
CONTROL
DEVICE
AUX +
FACP +
AUX --
FACP
MAG LOCK
MAG LOCK
ACCESS CONTROL
DEVICE
LOCK +
STRIKE +
TRG2
TRG1
COM --
NO RESET
SWITCH
FACP
MAG LOCK
ACCESS
CONTROL
DEVICE
LOCK +
STRIKE +
TRG2
TRG1
C
NO
NC
COM --
C
NO
NC
TRG1
TRG2
