DoorHan SHAFT-120 User Manual

OPERATOR
SHAFT-120
© DoorHan, 2012
Installation and Operating Manual
CONTENTS
GENERAL INFORMATION
SAFETY INSTRUCTIONS
OPERATOR UNIT
OPERATOR INSTALLATION
ELECTRICAL CONNECTIONS
ADJUSTMENT OF EXTREME POSITIONS
OPERATOR PROGRAMMING
RELEASE OPERATION
MAINTENANCE
TROUBLE SHOOTING
2
3
4
5
5
6
9
10
10
11
11

DoorHan SHAFT-120 Specifications

General

Manufacturer	DoorHan
Power supply	220V
Protection class	IP20
Maximum door width	3.5 m
Maximum door height	3.5 m
Opening speed	0.2 m/s
Closing speed	0.2 m/s
Operating temperature range	-20°C to +55°C
Type	Shaft
Operating temperature	-20°C to +55°C
