30 MAINTENANCE
7/26E, 7/31E, 7/41
TORQUE SETTING TABLE
ft lbf Nm
Airend to engine 29-35 39-47
Air filter to bracket 16-20 22-27
Autella clamp to exhaust 9-11 12-15
Baffle to frame 9-11 12-15
Blowdown solenoid valve 21-26 28-35
Discharge manifold to frame 29-35 39-47
Drive pins to engine flywheel 57-69 77-93
Drop Leg 53-63 72-85
Engine/airend to chassis 54-58 73-78
Euro-Loc adaptor to separator tank 58-67 78-91
Exhaust flange to manifold 17-21 23-28
Fan guard 9-11 12-15
Fan to hub 12-15 16-20
Lifting bail bracket to engine 29-35 39-47
Oil pipe (-12jic) 71-88 96-119
Radiator/Cooler to baffle 9-11 12-15
Running gear front to chassis 63-69 82-93
Running gear rear to chassis 63-69 82-93
Running gear drawbar to axle 29-35 39-47
Separator tank cover 40-50 54-68
Separator tank to frame 18-22 24-30
Service pipe (-20jic) 106-133 143-180
Sight glass 40-50 54-68
Wheel nuts 62-70 85-95
