OPTIONS 43
7/26E, 7/31E, 7/41
DESCRIPTION
This machine can be fitted with bund equipment to contain leakages
and spillages, which occur within the machine enclosure.
The bund will contain all fluids normally installed in the machine, plus
an additional 10%.
When fitted with bund, the machine must only be operated when level.
Rain water dropping through the top discharge grille on the canopy is
contained at the rear inner space of the machine and must be drained
daily. This space is sealed from the front inner space of the machine.
Drains for engine coolant, engine oil and compressor oil are located at
the front of the machine.
A drain for the rear space of the unit is located at the rear left side
behind the left hand fender.
DRAINING OF CONTAMINATED FLUIDS
Contaminated fluid must be removed by authorized personnel only.
Captured fluids can be drained from the bund by removing the plug or
uncoupling the flexible pipe secured at the left side of the machine. The
plug must be re-sealed after draining. The flexible pipe must be re-
secured after draining.
DRAINAGE OF MACHINE FLUIDS
During maintenance operations drain machine fluids using the drain
ports indicated.
Remove fuel tank to drain.
OPTION - BUNDED BASE
WARNING: Major leakages or spillages must be drained before
the machine is towed.
WARNING: The rear space of the unit must be drained daily of
any rainwater. Check and ensure correct tilt angle is attained
during draining.
