Dorel DL7519E - Hardware and Parts Identification; Hardware List

1
3
5 6
7
8
9
WOOD DOWEL
4 PCS
BARREL NUT
16 PCS
WOOD JOINT CONNECTOR (4mm HEX HEAD)
22 PCS
FLAT HEAD WOOD SCREW
24 PCS
WOOD DOWEL
34 PCS
10
TWIN BUNK BED
HARDWARE LIST
2
JOINT CONNECTOR (4mm HEX HEAD)
16 PCS
WOOD JOINT CONNECTOR (4mm HEX HEAD)
14 PCS
DL7519E / DL7519W
4
STOPPER
24 PCS
ALLEN KEY
1 PC
FLAT HEAD WOOD SCREW
6 PCS
∅11.8mm x
∅10mm x 50mm
∅19mm x 95mm
∅4mm x 30mm
∅4mm x 35mm
∅6.5mm x
∅1/4" x 100mm
∅6.5mm x 48mm
