KTC-2 (MS9)
4. Change the following in the UPS monitoring circuit:
- New terminal strips –X105
- Additional relay K7 (230VAC-version)
Exchange the old terminal strip –X105 by the new one and install the additional relay
K7. Wiring as follows:
NEW “K7”
