Dormakaba ALVARADO Argus V60 Installation Instructions

Argus V60 Installation Instructions
PUD4736R1-0
Page 11 support@alvaradomfg.com +1 (909) 591-8431 www.alvaradomfg.com
3.3 Environmental conditions
TheenvironmentalconditionsresultfromtheclimateclassicationaccordingtoICSandarethusbasedon
IEC721-3-3.Thefollowingenvironmentalconditionsmustbeobservedwhenoperatingtheinstalledunitinxed,
weather-protected areas.
Impairment of unit functions under extreme conditions
Extreme conditions include high humidity, aggressive air (e.g. salty), extreme temperatures and dirt.
• Atechnicalclaricationmustbeimplementedwithdormakababeforeorderplacement
Climate class Description
3K4 Temperature and humidity are not regulated at the operating location.
Temperature range: +41 to +104°F [+5°C to +40°C]
NOTICE
3.4 Technical specications
3.4.1 Argus V60
Power supply AC 100-240 V / 50-60 Hz
Connected load
2
300 VA
Power consumption
3
25 W
IP protection class IP 20
Noise emission < 70 dB(A),
according to Directive 2006/42/EC
Measured values: 51.3 dB
Dimensions of the standard unit
Passage width
Overall width
Width of one side element
Housing height
Upper edge of door wing
25-1/2" [650 mm]
45-3/4" [1161 mm]
7-1/8" [180 mm]
47-1/4" [1200 mm]
39" [990 mm]
Weight of one side element Approx. 88 lb [40 kg]
Frequency of passage 30 people/min.
Unit temperature range RA10-M05
Drive and locking device ETS22cc
Control unit ETS22cc
2 Theoretical maximum consumption during operation with maximum permissible nominal load
3 Standardized cycle with 1,000 passes per day and standby operation in between
