Dormakaba Quantum II RFID ECU - Page 6

6 Quantum II RFID ECU PK3724_T 05-19
.54
.72
2.05
1.71
2.37
3.25
1.63
1.81
.91
2.25
3.25
4X #6-32
TAPPED HOLE
C
L
C
L
4.56
4.48
ELEVATOR PANEL
4 Installation Steps
Surface Mount Reader
Figure 6
Surface Mount Reader
Installation Dimensions
Figure 7
Surface Mount Reader
Installation Template
