dosatron D14MZ10 - Disassemble Check Valve; Remove Check Valve Spring and Cone; Clean or Replace Check Valve Parts

Page 10
800-523-8499
www.dosatronusa.com
Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D14MZ10 Troubleshooting - Part 2
Step 9: Position the top guide over the shaft.
Step 8: Slide the spring over the shaft.
Step 7: Insert the cone into the top of the barb.
