Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D14MZ10 Troubleshooting - Part 3
Step 9: To replace the upper ange, (Part #: PDI643) grasp and
twist it counter clockwise.
Step 8: Insert the piston into the body. It should be a snug t.
NOTE: If either is loose, the anges need to be replaced.
Step 7: To test the lower ange, twist the plunger a quarter turn
counter clockwise and remove.
