Proper protection, such as gloves, eye wear, and aprons, are recommended when disassembling a Dosatron.
D14MZ10 Troubleshooting - Part 3
Step 15: To install the new ange, align the tooth inside the ange
with the notch in the piston shell.
Step 14: Remove by lifting straight up.
Step 13: To replace the lower ange, (Part #: PDI644)
grasp and twist it counter clockwise.
