DOSATRON INTERNATIONAL, INC. 800-523-8499
2
200 mesh /80
micron filter
Union ball
check/check
valve or
water
hammer
arrestor
Concentrate
Inlet Outlet
Optional accessories:
Pressure regulator
Solenoid valves
Water meter
Flow restrictor
STANDARD INSTALLATION
STANDARD INSTALLATION
Optional
accessories
