Standard linearization / [oFF
Use the up and down keys [
] to select [oFF.
Push [ENTER/MENUE] to confirm.
Calibration by code / oP1
Use the up and down keys [
] to select oP1. Push
[ENTER/MENUE] to confirm the desired setting. On
the bottom of the display a small 1 appears, after
this number a four-digit number (Hex-Code /0..F) is
displayed. For changing the number use the up key
[
] . For stepping to the next number use the key
down [
] . If the requested number is complete
then push [ENTER/MENUE] to confirm. Now on the
bottom of the display appears a small 2 and after this
number a second four-digit number is displayed. For
changing the number please follow the manual as
before. Push [ESC] to be back in the measuring
mode.
1.4.5 Channel activation
(only 2-channel instruments) / [Chnl]
Chnl = channel
To activate or deactivate a measuring channel
push [ENTER/MENUE]. Use the up and down keys
[
] to select Chnl. Push again [ENTER/MENUE].
On the left corner of the display appears a small 1,
which indicates the selected channel. For chang-
ing the channel use the up and down keys [
].
Push [ENTER/MENUE] to confirm. Use the up and
down keys [
] again to activate on or deactivate
off the requested measuring channel and push
[ENTER/MENUE] to confirm. Push [ESC] to be back
in the measuring mode.
Short-Cut: Press 2 seconds the HOLD/MAX/MIN-
Button for activate or deactivate channel 2.
Note: As a minimum one channel is active!
1.4.6 Enter Area for volume flow [ArEA]
To enter the area dimensions is only able with instru-
ments for measuring airflow.
CAL
oFF oP1 oP2
11
Important!
Unit
MENUE
Prob Lin2 CAL PrEn Chnl ArEA Lo6
DE P700 Anleitung engl. 12/11 06.12.2011 10:04 Uhr Seite 11
