: Setting 2 group table (Menu 2 = 2.PR)
※1 Password
It is necessary to input password to change or initialize parameters and default
value is “5”. Be sure to take notes not to forget or loss it after changing
password.
※2 Setup max. and min. range of pressure sensor
Setup max. and min. range of pressure sensor. Pressure sensor is a ratiometric
type of 0.5~4.5V. Default value before shipment is 1~15bar.
※3 Setup pressure sensor offset correction
Users can input offset correction value for pressure sensor, temperature sensor
and input error. It was set 0.0 as a default value.
※4 Jerk control ratio
Limit value of motor speed variation (Jerk Control)
※5 Expansion valve compulsory open ratio
If users want to temporarily control expansion valve by designated open ratio
while controlling normally. Default value before shipment is OFF.
※6 Sensor filter input time
Only expert can setup this parameter. If sensor input is excessively unstable,
increase filter value and make it stable.
※7 EEV compulsory open ratio
It can be used to temporarily control electronic expansion valve with designated
open ratio when controlling normally.
Default value is set as not in use.
※8 Way to change of display mode
Press up / downward button to change parameters
(DIS parameter will be changed)
Parameter number will be displayed for one second before parameter is
displayed.
* It is possible to change with direct input when displaying superheat set point.
※9 Initialization
If password is entered, parameters will be initialized as an default value before
shipment.
: Setting 2 group table (Menu 3 =
3.PR)
※ Users should input parameter which is suitable for characteristic of expansion valve. In case of difference,
it may be caused by malfunction or valve and system will be damaged.
Address Description Code Unit Step Min. Max. Default Custom
4 0061 Password
PCD
- 1 0 999 5
4 0062 Type of refrigerant
RFY
22(0)= R22
134(1)= R134A
404(2)= R404A
407(3)= R407C
410(4)= R410A
717(5)= R717
23(6)= R23
507(7)= R507C
22(0)
4 0063 Pressure sensor Max. range (at 4.5V)
PSH
bar 1 -1 99 15
4 0064 Pressure sensor Min. range (at 0.5V)
PSL
bar 1 -1 99 -1
4 0065 Pressure sensor offset correction
PCR
K 0.1 -9.9 9.9 0.0
4 0066 Temp. sensor offset correction
TCR
K 0.1 -19.9 19.9 0.0
4 0069
Jerk control ratio ※4
JEY
0.1 0.1 100.0 100.0
4 0070 Expansion valve open ratio upper limit
OPH
% 1 0 100 100
4 0071 Expansion valve open ratio lower limit
OPL
% 1 0 100 0
4 0072 EEV compulsory open ratio
O 11
- 0.1 0.1 10.0 1.0
4 0073 Sensor input filter time
UCR
% 0.1 0.0 100.0
OFF(-1)
4 0076 Display mode
D I S
0= 1~4 Rotation
1= Superheat
2= Evaporator outlet pressure
3= Expansion valve open ratio
4= Evaporator outlet temperature
5= Saturation temperature
1
4 0077 Run/Stop method
RMT
0= Always run 1= Digital input(RUN) 2= Communication Run 1
4 0078 Communication ID setup
ID
- 1 1 254 1
4 0079 Communication speed (BPS) setup
BDR
48(0)= 4800 96(1)= 9600 192(2)= 19200 384(3)= 38400
96
Initialization
RST
- 1 0 999 0
Address Description Code Unit Step Min. Max. Default Custom
4 0042 Expansion valve excitation type
EVD
1-2 = 1-2 phase excitation 2 = 2 phase excitation
2
4 0043 Expansion valve TOTAL PULSE
EVP
PULSE 1 100 999 200
4 0044 Expansion valve OPEN PULSE
EVO
PULSE 1 0 999 100
4 0045 Expansion valve DRIVE SPEED (PPS)
EVS
10(0)= 10PPS
20(1)= 20PPS
30(2)= 30PPS
50(3)= 50PPS
80(4)= 80PPS
100(5)= 100PPS
200(6)= 200PPS
250(7)= 250PPS
500(8)= 500PPS
200
