Parts Illustrations
Figure 1
Lock
Raise
Winch Guide
Pulley
Winch
Handle
Figure 3 Figure 2
Upper Pulley
Assembly
Locking Pin
Assembly
Locking Pin
Assembly
Tommy Bar
