Doyon LMF624 - Technical Data; Chapter 4 - Technical Data; A - General Dimensions LMF624

LSBLMF-A.DOC 09/09/05
9
CHAPTER 4
TECHNICAL DATA
4.1.A - GENERAL DIMENSIONS LMF624
The fig.4.1.A shows the machine’s dimensions.
Fig. 4.1.A
Model
Width
A [inch]
Length
B [inch]
Height
C [inch]
Width
D [inch)
Height*
H [inch]
LMF624 108 3/4 37 42 1/2 23 1/2 81 3/4
*When the tables are closed.
