DHG07-48/42 small cell power user manual<A>
8
–Self-cooling method.
–Small size and light weight.
⚫ Application diversity
–A variety of installation scenarios for poles, wall-mounted, channel steel, and angle steel.
–Supports both flag and flat installation.
⚫ Flexible combination
–The power modules are flexibly assembled, easy to expand.
− The power module is assembled with the lithium battery module.
⚫ Simplified operation
–Single easy installation.
–All the scenes use the same set of mounting parts.
–The input/output port and communication signal port adopt quick-connect terminals to prevent
foolproof and anti-reverse.
–Support plug and play, parameter free, communication free address setting.
⚫ Extended convenience
–Supports power module online expansion and increases system load capacity.
–Supports online expansion of lithium battery modules and increases system backup time.
⚫ Simple maintenance
–Support remote monitoring.
–Support Bluetooth connection and APP operation.
1.2 Main purpose and scope of application
The small cell power system is applicable to the mobile tower, telecommunication, mobile, transmission, access
network, as well as the private network field such as hydraulic power, army, public security, railway, bank,
computer center and other dc power supply system.
1.3 varieties and specifications；
varieties and specifications refer to sheet 1-3-1 2（KW）sheet 1-3-2（50AH）。
Sheet 1-3-1 Production model、specification（2KW）
