D+H RZN 4404-K V2 User Manual

RZN 4404-K
99.823.80 3.7/06/1999.823.80 3.7/06/19
20/36
RZN 4404-K
5/17
Intended use
- SHEV control panel in particular for staircases
- Microprocessor based control panel
- 1 line, 1 group
- 4A actuating current
- Comfort functions for daily ventilation
- Only for inside mounting
Operating voltage 230 V AC!
Risk of injury from electric shock!
- Connection has to be carried out only by an
authorized electrical specialist
- Only for inside mounting
- Just use unchanged original D+H parts
Safety notes
Smoke gases are to be carried off as unhindered
as possible through smoke and heat vent opening
in case of fire. Size, kind and arrangement of the
opening is of decisive significance for an optimal
effect of the smoke and heat vent system.
These requirements are defined in the relevant
regulations of the respective country.
More informations, are also available under
www.rwa-heute.de.
The SHEV opening should be coordinated with the
responsible fire protection authority.
SHEV opening
An overdue maintenance of the system will be
indicated by the control panel after about ca. 14 to
16 months.
The yellow LED in the smoke vent button will start
flashing.
A malfunction of the smoke vent system will be still
indicated by the extinction of the green LED in the
smoke vent button.
After the maintenance time is expired (approx. 14
to 16 months), the ventilation function OPEN can
be interrupted depending on the presetting of the
service timer.
Attention: Reset of the service timer can be
carried out by a specialist company only, who
has been authorized by the appliance
manufacturer.
Servicetimer
Inspection and maintenance has to be carried out
according to D+H maintenance notes. Only original
D+H spare parts may be used. Repair is to be
carried out exclusively by D+H.
Wipe away debris or contamination with a dry, soft
cloth.
Do not use cleaning agents or solvents.
Repair and cleaning
Observe regulations for danger warning systems
VDE 0833, guidelines for electrical systems VdS
2221, VDE 0100, DIN 18232 for smoke and heat
vent systems, regulations of the local fire-brigade
and of EVU for connection to mains supply.
Important regulations
Type ZP RZN 4404-K V2
Power supply 230 V AC, 50 Hz
Rated power 120 VA
Stand-by operating 5,8 W
Output voltage 24 V DC
Ripple 2 Vss, load-dependent
Output rated current 4 A
Number of lines / groups * 1 / 1
Fire detector per line max. 14 pcs.
SHEV button per line max. 8pcs.
Current per group ** max. 4 A
Mode of operation
- Monitoring Continuous duty
- Alarm / Ventilation Short-time duty (30 % DC)
Temperature range -5 ... +40 °C
* D+H Highspeed (HS) drives will be supported.
** The total current of the control panel must not be exceeded.
Housing GEH-KST GEH-S-RWA
Material Plastic with steel sheet door Steel sheet
Colour white light grey
Ingress protection IP 30 IP 54
Protection class II, with fuctional ground I
Dimensions WxHxD 310 x 310 x 100 mm 400 x 300 x 120 mm
Technical data
SHEV alarm
Malfunction
Mains existing
Vent button function "OPEN"
Smoke-/ vent button function "CLOSE"
Charging voltage regulator
Ground short
OPEN running time limitation
ventilation time limitation
Pictogram explanation
D+H window drive
OK
Control panel O.K.
min
15
2
45
30
sec
20
2
60
40
English
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this product.
Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
Electrical devices, accessories, batteries and packa-
ging should be sorted for environmental-friendly
recycling. Do not dispose electrical devices and
batteries into household waste!
Only for EC countries:
According the European Guideline 2012/19/EU for
waste electrical and electronic equipment and its
implementation into national right, electrcal devices
that are no longer usable must be collected separa-
tely and disposed of in an environmentally correct
manner.
Disposal
Declaration of Conformity
We declare under our sole responsibility that the
product described under “Technical Data” is in
conformity with the following directives:
2014/30/EU, 2014/35/EU
Technical file at:
D+H Mechatronic AG, D-22949 Ammersbek
Dirk Dingfelder Maik Schmees
Member of the Board Authorized signatory, Technical Director
20.03.2018
24 V - Emergency supply
Emergency power supply for 72 hours.
Use VdS approved storage batteries only!
2x 12V / 2,2 Ah ±0,3Ah (Type 2)
With connection of D+H alarm devices:
2x 12V / 3,4 Ah ±0,3 Ah (Type 8)
If the control panel is only operated with a max.
output current of 2 A, the following batteries are
sufficient for the emergency supply:
2x 12V / 1,2 Ah ±0,2Ah (Type 1)
With connection of D+H alarm devices:
2x 12V / 2,2 Ah ±0,3 Ah (Type 2)

D+H RZN 4404-K V2 Specifications

General

Brand	D+H
Model	RZN 4404-K V2
Category	Control Unit
Language	English
