D+H WRZ - Example for Application; System Configuration; Company Information

Lüftungsantrieb, 230V
ventilation drive, 230V
LT 230U
Lüftungstaster, 230V
vent button, 230V
WRG 82
Wind-Regen-Geber
wind / rain transmitter
RTR 230
Raumtemperaturregler
room temperature control
WRZ
max: 230V~ / 5A
Trennrelais
TRL 8
max: 230V~ / 5A
Trennrelais
TRL 8
TRL 8
Trennrelaismodule
cutoff relay modules
15
20
25
30
°C
10
5
I
0
