1
Alarm indicator
2 LCD Display
3 Laser /numeric decrease button
4
Mode button
5
Backlight/numeric increase button
6 Infrared sensor
7
Laser indicator
8 Backlight
9
Trigger button
10 Battery cover
1 Primary display panel: displays measured temperature.
2
Functional indication: displays Max, HAL(high alarm level), LAL(low alarm level),
E(emissivity)
3
Secondary display panel
4 Fahrenheit unit
5 Celsius unit
6 Low battery indicator
7
Temperature measurement indicator
8 Data hold
9 Laser on indicator (indicates that the laser is on)
