6 DR
®
TOW BEHIND FINISH MOWER
Figure 2
Hand Crank
Height Adjusters
DR 13.3 TQ
Engine
Tow Bar Locking Pin
Tow Bar
Tow Hitch
Oil Drain Tube
Fuel Fill
Oil Fill
Cap/Dipstick
Muffler
Front Caster
Wheels
Rear Fixed
Wheels
Discharge
Guard
Carbon
Canister
Fuel Filter
Left Side
Fuel Filter
Pull Start
Handle
Blade
Engage
Switch
Throttle
Control
Key Switch
Control
Panel
Chapter 2: Setting up the DR TOW-BEHIND FINISH MOWER
It may be helpful to familiarize yourself with the controls and features of your DR TOW-BEHIND FINISH MOWER by reviewing
Figure 2 or Figure 3 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR TOW-BEHIND FINISH MOWER Controls and Features (Pro 44TF Model)
Note: The model shown in Figure 2 may look slightly different from your machine.
