DR PILOT XT User Manual

CONTACT US AT www.DRpower.com 7
Snout Height
Adjuster Handle
Collection Bag
10″ Rear Wheels
Fuel Tank Cap
Vacuum Snout
Air Vent
Bag Top Cover
Vacuum
Housing
Snout Lid
Figure 2
Handlebar with
Foam Grip
Oil Fill/Dipstick
Air Filter
Chipper Chute
(XTSP Only)
Chute Tube
Self Propel
Drive Lever
(XTSP Only)
Drive Cable
Adjuster
(XTSP Only)
Muffler
Handlebar
Height Adjuster
Bag Holder
8″ Front Wheels
Chapter 2: Setting Up The DR
®
WALK-BEHIND LEAF AND LAWN VACUUM
It may be helpful to familiarize yourself with the controls and features of your DR WALK-BEHIND LEAF AND LAWN VACUUM
as shown in Figures 2a and 2b before beginning these procedures. If you have any questions at all, please feel free to contact
us at www.DRpower.com.
DR WALK-BEHIND LEAF AND LAWN VACUUM PILOT XT and XTSP Controls and Features

DR PILOT XT Specifications

General

Brand	DR
Model	PILOT XT
Category	Vacuum Cleaner
Language	English
