30 DR
®
TRIMMER/MOWER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – Main Frame Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 31130 Frame W/ Labels, TR4
2 34352 Engine W/ Label, B&S, 6.25, M/S, 50st
34353 Engine W/ Label, B&S, 6.25, E/S, 50st
34354 Engine W/ Label, B&S, 7.25, M/S, 50st
34355 Engine W/ Label, B&S, 7.25, E/S, 50st
32177 Engine W/ Label, Subaru, 7.52, M/S,
50st
32179 Engine W/ Label, Subaru, 8.26, E/S, 50st
3 14522 Screw, 3/8-16 X 1.5"
4 18081 Washer, Lock, 3/8", Split
5 31105 Guard, Debris
6 31117 Screw, HWH, 1/4-20 X .75", ZP
7 11238 Washer, Flat, 1/4" USS
8 31087 Pulley, Drive, 3l V-Belt, 7/8" Shaft
32157 Pulley, Drive, Double, 7/8 Shaft (SP
Only)
9 11155 Bolt, HCS, 3/8-24 X 3/4", ZP
10 31088 Belt, V, 3L, Gates 6744
11 31094 Pulley, Drive, 3L V-Belt, .67" Shaft
12 11914 Key, Square, 3/16" X 3/4"
13 12697 Washer, Fender, 1/4" X 1", ZP
14 31282 Guide, Belt
32340 Guide, Belt, Self Propel (SP Only)
15 31283 Nut, Lock, 1/4-20, Serrated Flange
16 31089 Bracket, Idler
17 31092 Pulley, Idler, 3L V-Belt, 2.0" OD
18 31093 Pulley, Idler, Flat, 1.99" OD
19 31091 Spacer, .385" X .62" X .219", ZP
20 31281 Strap, Belt Retainer
21 11075 Nut, Nylon Lock, 3/8-16, ZP
22 31090 Spring, E, .30" OD, .035" Wire, 3.0" L
23 12336 Bolt, HCS, 5/16-18 X 1-1/4", GR5, ZP
24 14360 Standoff, Clutch Arm
Ref# Part# Description
25 14375 Washer, .505" ID X 1" OD
26 11076 Nut, Nylon Lock, 5/16-18, ZP
27 27660 Pin, Belt Guide
28 11239 Washer, Flat, 3/8" USS
29 31096 Spindle, TR4
30 31131 Guard W/ Labels, TR4
31 31099 Spacer, .680" X .984" X .310", ZP
32 31098 Can, Anti-Wrap
33 31097 Plate, Line Spacer, D Bore
34 31101 Mow Ball, Hex Recess
35 31301 Bolt, HCS, 3/8-16 X 1", GR5, ZP, High
HD
36 31296 Bracket, Battery (E/S Only)
37 14386 Pad, Battery, 1.38" X 7.0" (E/S Only)
38 24749 Battery, 2.3Ah, 12V (E/S Only)
39 14385 Clamp, Battery (E/S Only)
40 18013 Bolt, Tri, 1/4-20 X 1" (E/S Only)
41 32160 Bracket, Cable, Self Propel (SP Only)
Not shown on Illustration:
31102 Cord Pack, 25", 12 Piece
19202 Label, DR Logo, 4" Round
13649 Label, Danger
13758 Label, Check Oil
14823 Label, Safety Icons
