DR PRO-XL User Manual

44 DR
®
LEAF and LAWN VACUUM
Chapter 6: Parts Lists and Schematic Diagrams
Parts List – FRAME AND CART ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 337931 Gas Spring, 500-300 mm, 150 Lb
2 337851 Handle Latch
3 337991 Frame, Rear
4 337941 Wheel and Tire, 14 X 5.3/4.50-8, 4 Ply
5 338021 Bracket, Axle
6 342561 Axle (Pro and Pro XL)
338011 Axle (Premier)
7 153421 Label-Dump Lever
8 372291 Label - Do Not Over Fill Oil
9 A0001469149 Support, Cart Bed
10 A0001234642 Support - Pivot - Cart Bed – Pro
A0001234644 Cart Bed - Premier
11 342581 Cart Bed (Pro and Pro XL)
337761 Cart Bed (Premier)
12 123341 Bolt-Hcs 3/8-16 X 1-3/4 Gr5 Zp
13 110731 Nut-Lock Nylon 1/4-20
14 160031 Pin-Hitch Clip 1/2-9/16
15 110241 Grip Latch Handle
16 111481 Bolt - 1/4-20 X 1 3/4 - Gr5 Zp
Ref# Part# Description
17 338031 Spring - C - 0.545od X 0.055 Wire X
2.2 L
18 A0000253563 Pin Clevis 1/2 X 4.5in L Zp
19 110761 Nut-Lock Nylon 5/16-18
20 333321 Nut-Nylon Lock Flanged 5/16-18
21 337981 Stud Ball - 10mm
22 126851 Pin Cotter 3/16 X 1 1/2
23 A0001216052 Washer-1.00 Id X 1.58 Od X .134
Thick
24 106681 Nut-Flange 5/16-18
25 350341 Bolt-Carr 5/16-18 X 3 Gr5 Zp
26 189801 Bolt - Hcs - 5/16-18 X 4-1/2 Gr2 Zp
27 338041 Washer .344 Id X .88 Od X .12
28 338051 Spacer-.327id X .51od X 2.69
29 350331 Bolt-Carr 5/16-18 X 1.75 Gr5 Z
30 A0000773052 Bracket - Foot Assist (Pro and Pro XL)
31 342791 Label, Operating
