LEAF and LAWN VACUUM
Parts List – POWER UNIT ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 333331 Nut-Nylon Lock Flanged 3/8-16 (Pro
and Pro XL)
333321 Nut-Nylon Lock Flanged 5/16-18
(Premier)
2 342391 Spacer, Impeller
3 354381 Engine W/Label, DR 16.96 TQ, E/S,
50st/CE (Pro XL)
354371 Engine W/Label, DR 16.96 TQ, M/S,
50st/CE (Pro XL)
354361 Engine W/Label, DR 13.28 TQ, E/S,
50st/CE (Pro)
354351 Engine W/Label, DR 13.28 TQ, M/S,
50st/CE (Pro)
354341 Engine W/Label, DR 9.59 TQ, E/S,
50st/CE (Premier)
354331 Engine W/Label, DR 9.59 TQ, M/S,
50st/CE (Premier)
4 A0000094783 Impeller
5 342441 Rod, Support Hose
6 A0001285658 Sideplate, Housing, Engine
7 388561 Sideplate - Housing Hose
8 388571 Scroll - Housing
9 388591 Adapter, Hose, Impeller Housing
10 A0001338018 Bracket-Rod Hose
11 A0001234648 Chute, Impeller Outlet
12 A0000543342 Frame - Front Ll2 W/ Weld Nuts
13 342771 Wheel, 4″
14 388621 Axle - Power Unit Ll2
15 342691 Jack Trailer (Pro and Pro XL)
16 137581 Label-Check Oil 2.75 In X .63 In
17 188871 Label-Hot Surface R/C
18 119831 Bolt-Hcs 1/4-20 X 3/4 Gr2 Zp
(Electric Start Only)
19 350401 Washer - Lock - 3/8 - Ext Tooth Zp
(Pro and Pro XL Electric Start)
112501 Washer, Star Lock, 5/16″ (Premier
Electric Start)
20 126831 Nut Finish - 3/8-16 (Pro and Pro XL
Electric Start)
110691 Nut Finish – 5/16-18, ZP (Premier
Electric Start)
21 123341 Bolt-Hcs 3/8-16 X 1-3/4 Gr5 Zp (Pro
and Pro XL Electric Start)
A0001686619 BOLT-HCS 5/16-18 X 2-3/4 IN GR5
ZP
Ref# Part# Description
22 111521 Bolt-Hcs 3/8-16 X 1 Gr5 Zp (Pro and
Pro XL)
23 114681 Bolt - Hcs 1/4-20 X 1 1/4 Gr5 Zp
24 110731 Nut-Lock Nylon 1/4-20
25 234991 Washer - 0.53 Id X 1.06 Od X 0.095 -
Zp
26 235001 Pin - Cotter 7/64 X 1 Zp
27 265561 Bolt - 1/2-13 X 2 3/4 - Gr 5 - Tb
28 333351 Nut-Nylon Lock Flanged 1/2-13
29 211541 Pin-Clevis 1/2x3.5in L Zp
30 160031 Pin-Hitch Clip 1/2-9/16
31 A0000253563 Pin Clevis 1/2 X 4.5in L Zp
32 350231 Bolt-Hex Flange 5/16-18 X .75
33 A0000072109 Bolt-Hcs 5/16-24 X 2-7/8 Gr8 Yzp
34 350361 Washer - Flat - 0.344 X 1.25 X 0.25 Zp
35 350321 Washer-Lock 5/16 Gr8 Yzp
36 110761 Nut-Lock Nylon 5/16-18
37 123211 Bolt-Hcs 5/16-18 X 3/4 Gr5 Zp
38 187551 Nut Nylon Lock - 5/16-18 Lp
39 333321 Nut-Nylon Lock Flanged 5/16-18
40 386401 Bolt-Hcs 5/16-18 X 6 Gr5 Zp
41 386501 Bolt-Hcs 5/16-18 X 6.50 Gr5 Zp
42 119851 Bolt - Hcs - 3/8-16 X 1 1/2 - Gr5 Zp
43 189671 Washer-Rubber 1/2id 1od
44 134471 Battery 9 Ah 12v (Electric Start Only)
45 242301 Strap-Battery 9ah Ll1
46 342751 Wire Battery Ground-Ll2
47 342761 Wire Battery - Positive Ll2
48 A0002032108 Cable - Collector - Ll3
Not Shown
370361 Wire Tie
342781 Label, Warning, Chute & Hose
A0000221923 Label, Premier 200
A0000221926 Label, Pro 321
A0000221928 Label, Pro XL321
To Next Page
