DR PRO-XL User Manual

48 DR
®
LEAF and LAWN VACUUM
Parts List – COLLECTOR ASSEMBLY
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 A0001049408 Tube, Hinge, Collector Frame, RH
(Pro and Pro XL)
A0001049410 Tube, Hinge, Collector Frame, RH
(Premier)
2 A0001049405 Tube, Hinge, Collector Frame, LH
(Pro and Pro XL)
A0001049409 Tube, Hinge, Collector Frame, LH
(Premier)
3 A0001049393 Frame, Tube, Collector, RH
4 A0001049390 Frame, Tube, Collector, LH
5 337901 Retainer, Enclosure, LH
6 A0001074969 Enclosure, Fabric (Pro and Pro XL)
A0001074967 Enclosure, Fabric (Premier)
7 A0001049371 Link, Offset, Collector (Pro and Pro
XL)
A0001049378 Link, Flat, Collector (Premier)
8 A0001049375 Link, Flat, Collector (Pro and Pro
XL)
A0001049372 Link, Offset, Collector (Premier)
9 A0001048637 Retainer, Ring, Link
10 337911 Retainer, Enclosure Front
11 A0001049398 Hinge, Split, Frame Collector, RH
(Pro and Pro XL)
A0001049402 Hinge, Split, Frame Collector, RH
(Premier)
12 A0001049396 Hinge, Split, Frame Collector, LH
(Pro and Pro XL)
A0001049399 Hinge, Split, Frame Collector, LH
(Premier)
13 A0001049385 Handle, Tube Frame (Pro and Pro
XL)
A0001049389 Handle, Tube Frame (Premier)
14 A0001048632 Bracket, “L”
15 110731 Nut, Nylon Lock, 1/4-20
16 110761 Nut, Nylon Lock, 5/16-18
Ref# Part# Description
17 119851 Bolt, HCS, 3/8-16 X 1 1/2″, GR5, ZP
18 334431 Link, Chain, Threaded Connector
19 342551 Pin, Hinge (Pro and Pro XL)
337861 Pin, Hinge (Premier)
20 350281 Eyebolt, 5/16-18 X 2″, Forged, ZP
21 350231 Bolt, Hex, Flange, 5/16-18 X .75″
22 350271 Bolt, C-Head, 5/16-18 X 1.75″, ZP
23 112411 Washer, Flat, 5/16″, USS
24 110751 Nut, Nylon Lock, 3/8-16
25 A0001844373 Bracket, Stop
26 337871 Pin, Cotter Hair, 1/4″ - 3/8″
27 350301 Knob, 5/16-18, W/Lock, 1.16 Dia
28 101471 Bolt, HCS, 5/16-18 X 2-1/4″, GR2
ZP
29 123371 Bolt, HCS, 3/8-16 X 2-3/4″, GR5, ZP
30 164131 Nut, Nylon Lock, 3/8-16, Lowpro
31 150451 Bolt, HCS, 5/16-18 X 1-3/4″, GR5,
ZP
32 337891 Retainer, Enclosure, RH
Not Shown
361201 Batten, 40” PRO
361191 Batten, 28.5” PREMIER
