DR PRO-XL User Manual

8 DR
®
LEAF and LAWN VACUUM
Chapter 2: Setting Up the DR LEAF and LAWN VACUUM
It may be helpful to familiarize yourself with the controls and features of your DR LEAF and LAWN VACUUM as shown in Figure 1
before beginning these procedures. If you have any questions at all, please feel free to contact us at www.DRpower.com.
DR LEAF and LAWN VACUUM Controls and Features
Collector Sleeve
Hose Support
Dump
Lever
Collector
Outlet
Chute
Cart Bed
Power Unit
Wheels
Figure 1
Pneumatic
Tires
Tow Hitch
Dump
Handle
Jack
Battery (Electric
Start Models)
(Manual start)
On/Off
Switch
Choke
Air Filter
Gas Shut-Off
Starter Recoil Handle
Key
Switch
Gas Fill
Inlet Hose Assembly
Cable
(Electric start)
Muffler
Throttle
Choke
Air Filter
Gas Shut-Off
Starter Recoil Handle
Gas Fill
Muffler
Throttle
Foot Assist
(Pro Models Only)
