DR VERSA TRAILER PRO XL2000 - Crane and Boom Assembly Parts List

32 DR
®
VERSA TRAILER™
Parts List and Schematic – DR VERSA TRAILER Crane and Boom Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 299651 Front Bed Support
02 299731 Crane Pivot Lock
04 299861 Manual Winch w/Cable
05 302641 Winch Cable, 1/4" x 25'
06 302691 Crane Boom Subassembly
07 302751 Safety Snap Pin, 6.25 x 55mm
08 302391 Bolt, HHCS, M12-1.75 x 50mm Class 8, ZP
09 302401 Hex Nut, Heavy, M12-1.75, Class 8, ZP
10 302621 Lock Nut, Nylon, M14-2
11 302611 Bolt, HHCS, M14-2 x 140, Class 8, ZP
12 302571 Pivot Lock Spring
13 302461 Lock Nut, Flange, Nylon, M8-1.25
14 302451 Bolt, HHCS, M8-1.25 x 30, Class 8, ZP
15 299741 Pivot Lock Handle
16 302561 Pivot Lock Tab Spring
17 277201 Lock Nut, Nylon, M20-2.5
18 302591 Fairlead Roller
19 302461 Lock Nut, Nylon, M8-1.25
20 302491 Lock Nut, Nylon, M10-1.5
21 299761 Boom Crane Pivot
22 302581 Boom Pivot Pin
23 160031 Hitch Clip Pin, 1/2" to 9/16", .12" Wire
Ref# Part# Description
24 302601 Bolt, HHCS, M8-1.25 x 100, Class 8,
ZP
25 302631 Bolt, HHCS, M10-1.5 x 55, Class 10,
ZP
26 302551 Bolt, HHCS, M16-2 x 110, Class 10, ZP
27 302541 Lock Nut, Nylon, M16-2
28 302821 Washer, M20
29 A0001618878 Boom Crane, w/Label
30 277341 Boom Pulley Pin
31 160031 Hitch Clip Pin, 1/2" to 9/16", .12" Wire
32 277171 Boom Pulley Bracket
33 302391 Bolt, HHCS, M12-1.75 x 50, Class 8,
ZP
34 277381 Boom Chain
35 277211 Boom Pulley, 104mm
36 293981 Load Rating Label
37 302521 Washer, M12
38 302531 Lock Nut, Nylon, M12-1.75
39 299721 Vertical Crane Support
40 299751 Cable Roller, 55mm
41 302611 Bolt, HHCS, M14-2 x 140, Class 8, ZP
42 302621 Lock Nut, Nylon, M14-2
43 293981 Label, Load Rating
