DR VERSA TRAILER PRO XL2000 - Main Frame and Axle Assembly Parts List

34 DR
®
VERSA TRAILER™
Parts List – DR VERSA TRAILER Main Frame and Axle Assembly
Note: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 302711 Tow Bar w/Labels
02 299581 Axle and Hub Assembly
03 299641 Wheel and Tire Assembly, Off Road
04 302441 Axle Pivot Pin
05 277201 Lock Nut, Nylon, M20-2.5
06 277191 Bolt, M20 x 110
07 299781 Lug Nut
08 302391 Bolt, HHCS, M12-1.75 x 50, Class 8, ZP
09 302401 Hex Nut, Heavy, M12-1.75, Class 8, ZP
10 302451 Bolt, HHCS, M8-1.25 x 30, Class 8, ZP
11 302461 Lock Nut, Nylon, M8-1.25
12 302471 Washer, M8
13 299601 Wheel Stud
14 299611 Wheel Dust Cap
15 302421 Taper Roller Bearing, 30206M
16 302411 Taper Roller Bearing, 30204M
17 253111 Cotter Pin, 3/16" x 2.5"
18 302431 Hex Nut, Slot, M18-1.5, Class 8, ZP
19 299621 Axle
20 299591 Wheel Hub
21 294011 Label, Towing
Not Illustrated:
253111 Cotter Pin, 3/16" x 2-1/2"
