Dräger PSS Merlin System

Technical Data
10 | Dräger PSS
®
Merlin
®
System
Dräger PSS
®
Merlin
®
System
Size Weight Volts
Dräger PSS PC Modem 135 x 120 x 40 mm 0.5 kg 5 V
Dräger PSS Merlin Entry
Control Board
450 x 780 x 70 mm 9 kg 7.2 V
Dräger PSS Merlin Modem
(only for Dräger PSS
5000/7000)
170 x 130 x 30 mm 0.44 kg 6.5 V
Dräger Bodyguard 7000 150 x 74 x 41 mm 0.35 kg 7.5 V
Dräger PSS Merlin Repeater 450 x 210 x 100 mm 2 kg 6.5 V
Range: 3 km (line of sight)
Transmission Power: 500 mW
Recommended minimal system requirements Dräger PSS
Merlin Software
Operating System: Microsoft Windows XP
Processor: 2.33 GHz (1.6 GHz for Netbook or Tablet PC)
RAM: 128 MB (1 GB for Netbook or Tablet PC)
Graphic Board: 128 MB
Ports: USB 2.0
APPROVALS
Dräger PSS
®
Merlin
®
System:
EN 137: Type 2 (Modem and Dräger Bodyguard 7000) R&TTE (EMC) 1999/5/EC (Telemetry Components)
ATEX 94/9/EC (Modem and Dräger Bodyguard 7000) EN 300 220-2 (Telemetry Components)
EN 50303 (Modem and Dräger Bodyguard 7000) EN 300 330-2 (Telemetry Components)
EN 60079-0 (Modem and Dräger Bodyguard 7000) EN 301 489-3 (Telemetry Components)
EN 60079-11 (Modem and Dräger Bodyguard 7000) EN 60950 (Telemetry Components)
EN 60079-26 (Modem and Dräger Bodyguard 7000)
Emark 2004/104/ec (Vehicle Charger)
Ordering Information
Dräger PSS
®
Merlin
®
System
Freq (MHz) Order Number
Dräger PSS Merlin PC Modem (incl.
Software)
450-470 33 60 895
Dräger PSS Merlin Entry Control Board 450-470 33 54 270
Dräger PSS Merlin PC Modem (incl.
Software)
869.5 33 59 792
Dräger PSS Merlin Entry Control Board 869.5 33 51 145
Accessories Dräger PSS Merlin PC
Modem
PSS Merlin PC Modem Tablet Adaptor 33 60 295
RFID Tallies (5 pcs.) 33 60 838
