Dragonfly 32 Swing Wing - Page 76

Rope diagram
Dragonfly 32 Swing Wing Evolution Version
Text
Material
No of lines
Diameter
Length in metres
Main sheet
Polyester
1
10 mm
30 m
Backstay
Dyneema
2
10 mm
20 m
Backstay
with eye-splicing in both ends
Dyneema /
Carbon
2
8 mm
4.4 m
incl. eye-splicing
Genoa sheet
Polyester
1
12 mm
24 m
Main traveller outhaul
Polyester
1
8 mm
14 m
Genoa traveller outhaul
Dyneema
2
8 mm
13.5 m
Asymmetric spinnaker sheet
Polyester
1
10 mm
46 m
Genoa furler
Dyneema
1
8 mm
18 m
Tack line
Dyneema
1
8 mm
20 m
Swing Wing line
Dyneema
2
8 mm
27 m
Barberhaul
Polyester
2
8 mm
26 m
Centerboard up
Dyneema
1
8 mm
10 m
Centerboard down
Dyneema
1
8 mm
12 m
Preventer/boomvang
Polyester
2
8 mm
15 m
Lazy-Jack
Polyester
1
6 mm
18 m
Lazy-Jack on spreader
Polyester
2
6 mm
2.5 m
Mooring lines
Polyester
4
16 mm
14 m
Main halyard
Dyneema
1
8 mm
57 m
Genoa halyard
Dyneema
1
10 mm
36 m
Spinnaker halyard
Dyneema
1
8 mm
41 m
Code 0 halyard
Dyneema
1
8 mm
38 m
Reef 1
Dyneema
1
8 mm
20 m
Reef 2
Dyneema
1
8 mm
35 m
