6. TECHNICAL DESCRIPTION
– 9 –
6.1 IDENTIFICATION
(1) Carry handle.
(2) Input fuse.
(3) Power boost switch.
(4) Ventilation grilles.
(5) Mains plug and cable.
(6) 12/24V Selection switch.
(7) Output fuse.
(8) Ammeter – output charge current.
(9) Positive (Red) clamp.
(10) Negative (Black) clamp.
Stock No.52985 shown
(9)
(10)
(1)
(8)
(7)
(2)(6) (3) (4)
(5)
