DRAX ELLIPTICAL Series - Installation; Precautions; Part Name

To Next Page

To Previous Page

①

⑤

⑦

⑥

⑧

⑨

⑩

④

②

③

⑪

① D i s p l a y

④ T o u c h T y p e H e a r t r a t e

⑦ C u p H o l d e r

⑩ H a n d l e

② O p e r a t i o n P a n e l

⑤ C o n s o l e C o l u m n

⑧ F o o t

⑪ O p e r a t i o n P a n e l

③ USB & E a r p h o n e

⑥ c o n s o l e

⑨ P e d a l

(1) The Elliptical should be installed on a flat place and horizontally aligned. If the Elliptical is

placed on unstable pad or carpet, the belt may not be correctly arranged. In this case the Elliptical will

be overloaded and trouble can occur.

(2) Please be sure to use a standardized plug which should be earthed

Precautions

Part Name

Installation
