Vigor2860 Series User’s Guide
9
There are two types of antennas provided for Vigor2860Ln, which must be installed in
different locations carefully and correctly. Wrong installation might cause bad signal of
wireless connection. Therefore, pay attention to the installation of antennas by referring to the
following illustration.
Holes fo
r
Antennas without
Socket
Holes for Antennas
with Socket
