-4-
INSTALLATION
This lamp is intended only for outside use.
Choose a stable, solid and supportive surface and make sure the lamp is mounted with
the solar panel faced towards the sun. Mounting height is 3~5 meters.
There are 2 installation options:
1.Wall mount
Using the supplied normal screws
for wall panels or using the supplied
expansion screws for brick walls
360°
360°
135° 135°
• Use the supplied screwdriver (side with the torx screwdriver) to loosen the bracket.
Adjust the bracket to the appropriate angle and x the screw tightly.
• Pull out the light panel and adjust it to the preferred lighting angle. Fix the screw
tightly with the supplied screwdriver (side with the normal screw driver).
• Fix the lamp onto the wall or pole using the correct mounting parts.
MOTION SENSOR RANGE
The SPL-1000 has 2 motion sensors, one on each side of the lamp. Complete detection
area is 180°. Actual range of the motion detection sensor depends on mounting height.
OPERATION
The SPL-1000 has 3 lighting modes, which can be selected using the Mode buttons.
ON/OFF BUTTON: LIGHT ON/OFF
2.Pole mount
Using the supplied pole mount part
