Code No. Part No. *Description
01 2615302324 *Router Base
02 529495170 *Depth Adjustment Bracket
03 529495270 *Tool Holder
04 529495370 *Depth Adjustment Screw
05 529495470 *Edge Guide Bracket
06 529495570 *Edge Guide
07 529495670 *Carriage Bolt #10 - 24 x 1 1/4 3 Req’d.
08 529495770 *Guide Rod 2 Req’d.
09 2615302325 *Router Bit Storage Handle 2 Req’d.
10 2615297532 *Clamp Knob
11 529422770 *Washer 3/16 I.D. 3 Req’d.
12 529496070 *Bracket Mounting Screw (#8 x 1”) 2 Req’d.
13 529496170 *Type One Bushing
14 529496270 *Small Body Bushing Set of Two
15 529496370 *Rod Clamp Screw #10 - 24 x 3/4 R.D. H.D. 2 Req’d.
16 529496470 *Square Nut #10 - 24 x 3/8 x 1/8 3 Req’d.
17 529496570 *Compass Point Nail
18 529422370 *Clamp Screw Nut 2 Req’d.
19 529420570 *Clamp Screw #6 - 32 x 3/4 Hex H.D. M.S. 2 Req’d.
20 0326578 *Storage Knob Mounting Screw - (#2 x 1/2”) 2 Req’d.
21 529495970 *Wing Nut #10-24 2 Req’d
-21-
*Available in hardware stores.
