Page 11
Ref. No. Part Part No.
1 Depth Guide Cutting Base Plate 2610916273
2 Depth Guide Wingnut (pair) 2610914431
3 Depth Guide Nut Plate 2610913184
4 Depth Guide Retainer 2610916274
5 Retainer nut 3603301505
6 Collet nut 2610913319
7 1/8" Collet 2615295093
8 Wrench 2615295097
9 Shaft lock assembly 2610907116
10 Shaft lock retaining ring 2610909201
11 Brush caps (pair) 2610913159
12 Motor brushes and springs (pair) 2610913160
13 Motor brush holder with straight lead 2610915244
14 Motor brush holder with right angle lead 2610915245
15 Cap for on/off switch 2610913156
16 On/off switch 2610996245
17 Power cord 2610913157
18 Speed control assembly 2610913155
19 Motor assembly 2610914664
20 Field assembly 2604220677
21 Rubber isolator ring 2615297373
22 Screws (five) 2610326578
23 Handle assembly 2610913023
24 Housing set with labels 2610907339
25 Tool hanger 2610913164
Order by part number, not reference number.
Write for current price or call 1-800-4 DREMEL
Dremel Advantage™
Service Parts List
