Mongoose Capabilities
Below is a table of the capabilities that the manufacturer’s service
subscriptions provide with your Mongoose:
Chrysler FORD GM ISO/CAN JLR TOYOTA
Factory Diagnostics • •
Re-flashing • • • • • •
Key re-programming • • • •
Jaguar/Land Rover and Toyota provide dealer level capability.
Drew Tech also offers DashDAQ-PC software application to read
Diagnostic Trouble Codes and data-log generic and manufacturer-
specific OBDII parameters. Obtain a free 30 day trial of DashDAQ-
PC by visiting www.drewtech.com
Specifications and Pin-out
Currently there are six variations of the Mongoose J2534 device:
• Mongoose-Chrysler
• Mongoose FORD
• Mongoose GM
• Mongoose ISO/CAN
• Mongoose-JLR
• Mongoose Toyota
Mongoose vehicle connector pin assignments:
Pin
#
Chrysler FORD GM ISO/CAN JLR TOYOTA
1 SW CAN PS GND
2 J1850+ J1850+ J1850+ J1850+ J1850+
3 CAN 2+/K-
LINE
4
5 GND GND GND GND GND GND
6 CAN+/SCI CAN+ CAN+ CAN+ CAN 1+ CAN+
7 SCI K-Line K-Line K-LINE K-Line
8 ROSCO
9 SCI PS GND
10 J1850- J1850-
11 CAN 2-
12 SCI PS GND PS 5V
13 FEPS FEPS
14 CAN-/SCI CAN- CAN- CAN- CAN 1- CAN-
15 L-Line/PS
GND
L-Line L-Line L-LINE
PS GND
SCI
16 VBatt VBatt VBatt VBatt VBatt VBatt
PS GND = Pin Switched to Ground
PS 5V = Pin switched to +5V
