SPECIFICATIONS
Model SAHARA SAHARA PRO SIROCCO VORTEX
Switch 2-Speed Rocker 3-Speed Rotary 3-Speed Rotary 1-Speed Rocker
Actual CFM 900 - 1200 cfm
1530 - 2050 cmh
800 - 1000 - 1200 cfm
1350 - 1700 - 2050 cmh
1,850 cfm (high)
3
,
140 cmh
(
hi
g
h
)
3,600 cmh
2
,
120 cfm
Rated CFM 2,700 cfm
4
,
600 cmh
2,700 cfm
4
,
600 cmh
4,900 cfm
8
,
300 cmh
N/A
RPM 800 - 1,075 rpm 700 - 900 - 1,075 rpm 650 - 900 - 1,350 rpm 2,850 rpm
Static Pressure 3.8 cm, 1.5" 3.8 cm, 1.5" 5.8 cm, 2.3" 5.6 cm, 2.2 in
Power, 230 Volts 4.7 amps 4.7 amps 4.2 amps 2.2 amps
Carpet Clamp Kit Available Yes No N/A
Kickstand Yes Yes Yes N/A
Positions 3421
Wheel 9.5" x 9.5"
24 x 24 cm
9.5" x 9.5"
24 x 24 cm
10.5" x 10.5"
27 x 27 cm
N/A
(
Axial fan-blade
)
Height, Width, Length 20", 15", 20"
50
,
44
,
50 cm
20", 15", 20"
50
,
44
,
50 cm
21 x 19 x 22 in.
53 x 48 x 56 cm
19", 15",18"
48
,
38
,
46 cm.
Use Weight 13 kg, 28 lb 13 kg, 28 lb 19 kg, 42 lb 15 kg, 33 lb
Ship Weight 16 kg, 35 lb 16 kg, 35 lb 22 kg, 49 lb 19 kg, 41 lb
Motor Rating .4 hp .4 hp .75 hp 1.0 hp
Overheating Cutoffs Dual Thermal Protectors Dual Thermal Protectors Dual Thermal Protectors Dual Thermal Protectors
Safety Listings CE CE CE CE
Warranty 1 Year Limited 1 Year Limited 1 Year Limited 1 Year Limited
Specifications are subject to change without notice. Some values are approximate.
TROUBLESHOOTING
In COLUMN 3, the technician in the field can handle "FS" or Field Solutions. Others solutions should be handled by a repair technician – an
"AST" or Authorized Service Technician.
WARNING: Execute all the service procedures below only with power turned off, i.e. unplugged.
PROBLEM CAUSE
See
above SOLUTION
Motor won't run No power to machine FS Plug in the unit; check circuit breaker or fuse
Switch not turned on FS Turn on the switch
Blower wheel jammed FS Remove material jamming wheel
Intake or exhaust blocked FS Turn machine off and allow to cool, then remove blockage
Switch is broken AST Call distributor or Dri-Eaz for replacement switch
Loose wiring AST Check wiring and tighten as needed
Motor runs but wheel turns
erratically or scrapes
Severe jolt has caused motor mount to
bend and wheel to rub
AST Remove motor from housing, then replace or repair bent
motor mount
Severe jolt caused motor to slip out of
mount and wheel to rub
AST Remove motor from housing, then install motor into mount
correctly
Unit vibrates excessively Accumulation of soil on wheel FS Clean blower wheel
Blower wheel has lost balance AST Balance or replace blower wheel
Blower wheel has been bent AST Replace blower wheel
Bent motor shaft AST Replace motor
FOR PARTS AND SERVICE CALL YOUR LOCAL DISTRIBUTOR,
or the Dri-Eaz Service Department at (360) 757-7776
