Drill Master 3733 - Page 13

Page 13SKU 3733 For technical questions, please call 1-800-444-3353.
Blade Guard (8)
Table (1)
Lever (9)
Power Switch (4)
Angle
Gauge (21)
Body (19)
Rip Fence (7)
FIGURE 2
Bench Stop (22)
Outer Flange (36)
4” Blade
(Not Included)
Nut (37)
Outer Flange (36)
Remove Screw (16)
to Remove Table (1)
FIGURE 3
Arrow Points To
FRONT of Tile Saw
Nut (37)
4” Blade
(Not Included)
