2 HP Fixed Base Router
68341 Router
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-800-444-3353 as soon as possible.
Visit our website at: http://www.harborfreight.com
Copyright
©
2011 by Harbor Freight Tools
®
. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

Questions and Answers

  • R
    Rodney RojasJul 31, 2025
    What to do if my Drill Master 68341 will not start?
    • M
      mcintyresophiaJul 31, 2025
      If your Drill Master Wood Router won't start, there are several potential causes: 1. The cord may not be connected. Ensure the cord is properly plugged in. 2. There may be no power at the outlet. Check the power at the outlet and the circuit breaker. If the breaker is tripped, ensure the circuit has the correct capacity and no other loads. 3. The tool's thermal reset breaker may have tripped (if equipped). Turn off the tool, allow it to cool, and then press the reset button on the tool. 4. There may be internal damage or wear. In this case, have a qualified technician service the tool.
  • F
    floreslanceAug 7, 2025
    Why is my Drill Master Wood Router overheating?
    • S
      Shelley WoodAug 8, 2025
      Your Drill Master Wood Router may be overheating due to several reasons: 1. You might be forcing the tool to work too fast; allow it to work at its own pace. 2. The accessory might be misaligned; check and correct the alignment of the accessory to the fence and/or table. 3. The accessory could be dull or damaged; keep cutting accessories sharp and replace them as needed. 4. The motor housing vents might be blocked; use compressed air to blow dust out of the motor while wearing safety goggles and a dust mask/respirator. 5. The motor might be strained by a long or small diameter extension cord; eliminate the use of an extension cord, or use one with the proper diameter for its length and load.
