1. Remove the Plug (63)
2. Fill：While put the water inlet A (the shorter pipe)
into the prepared water, put the water outlet B (the
longer pipe) into the tank. Drawing the water to the tank
by squeezing the hand pump C repeatedly. Or injecting
water with the Funnel (T3) supplied.
3. Empty：Conversely, put the shorter pipe A into the
tank and the longer pipe B into the container prepare.
Pumping C to draw the water out of the tank.
4. Replace the Plug (63).
5. Remove the Pump Cover D to release the water
inside.
Transportation
How to fill and empty the tank
Up-lifting the machine as shown and you may
transport the machine with two transporting
wheels in the Front Stablizer (A3).
