Accessories: Cane holder
ASSEMBLY INSTRUCTIONS
www.drivemedical.de
Drive Medical GmbH & Co . KG • Leutkircher Straße 44 • D-88316 Isny/Allgäu • Germany • info@drivemedical.de • Tel.:
+49 7562 9724-0
• Fax:
+49 7562 9724-25
Diamond und Diamond Deluxe
ROLLATOR
Assembly
Remove this bolt on the holder for the front
wheel (either on the left or right side) and
insert the cane holder cup with the bolt
supplied as shown below. Then tighten the
bolt again!
ATTENTION: Ensure correct position of
the washer!
Fix the Velcro© tape to the lower tube of
the handle by fastening the press-stud and
adjust Velcro© tape to cane diameter.
As per: 06/2013
